Panasonic PT-DZ21KE

1920 x 1200 resolution - 20,000 lumens

Overview

The PT-DZ21KE is part of Panasonic's flagship PT-DZ21K projector series, and offers breathtakingly beautiful images, easy maintenance, and reliable operation.

20,000 lumens of brightness, and a host of rich creative capabilities, are packed into an extraordinarily compact body; with every feature designed and developed to meet the projection needs of highly critical professionals, across the full spectrum of applications.

Contrast, depth, and clarity are integral to the PT-DZ21KE. Its four-lamp system enables stable extended operation, with quad, triple, dual and single-lamp modes allowing for continual projection, 24/7. This projector also boasts stunning 3D projection capabilities, offering both passive and active 3D projection system compatibility for the viewing of 3D images.

Features

20,000 Lm of brightness - and rich creative capabilities in WUXGA resolution
Ultra-compact design
1920 x 1200 Native Resolution
16:10 Native Aspect Ratio
10,000:1 Contrast Ratio
Approx. 43kg (94.8lbs) (without lens)

Technical Specification

Power supply 200-240V AC, 50/60 HZ (Max. current requirements: 12A @200V)
Power consumption 2,300W (0.3W with standby mode set to eco, 9W with standby mode set to normal.)
Dissipation BTU Max. 7,848 BTU/hour (without light output: 7,585 BTU/hour)
DLP™ chip panel size 24.4mm (0.96in) diagonal (16:10 aspect ratio)
DLP™ chip display method DLP™ chip x 3, DLP™ projection system
DLP™ chip pixels 2,304,000 (1,920 x 1,200) x 3, total of 6,912,000 pixels
Lamp 465W UHM lamp x 4, replacement cycle of up to 2,000 hours
Brightness 20,000 Lumens (four-lamp)
Center-to-corner uniformity 90%
Contrast 10,000:1 (full on/off, with dynamic iris set to "3")
Resolution 1,920 x 1,200 pixels
Optical axis shift - Vertical ± 55% (± 44% with the ET-D75LE6) from center of screen (powered)
Optical axis shift - Horizontal ± 20% (± 15% with the ET-D75LE6) from center of screen (powered)
Keystone correction range Vertical: ±40°, horizontal: ±15°
Dimensions
(W x H x D)
620mm x 291mm x 800mm
Weight Approximately 43kg (94.8lbs)
Operation noise 49dB (quad lamp operation)
Operating environment Operating temperature: 0-45°C (32-113°F)
Operating humidity: 10-80% (no condensation)
