Christie Boxer 4K30

4096 x 2160 resolution - 30,000 lumens

Overview

The Christie Boxer 4K30 represents a major advancement in projection technology offering many new technical and creative possibilities. It is now possible to easily display broadcast and consumer 4K video content at native resolution and to massively improve the quality of all presentations.

For blended UltraWideScreens the Boxer's 4096 x 2160 resolution and incredible 30,000 lumens can reduce or eliminate the amount of blending as well as decrease the numbers of projectors required.

The compact chassis can be easily handled by two technicians, and with 360° omnidirectional operation and single phase power it's easy to see why the Boxer will quickly become the first choice for all large scale projection mapping projects.

All the most familiar feature sets are there, together with major enhancements to make operation even easier and more responsive, as well as providing easy-access on-board servicing and maintenance facilities. Christie's TruLife™ electronics ensure stunning colour reproduction and expert image manipulation, with blending functionality provided by 4K Twist software.

Features

It's the brightest, lightest and smartest 30,000 lumen projector at 150 lbs
Single phase power reduces set-up cost and complexity
At-a-glance source and status updates on lamp hours, voltage, temperature, warnings or errors, from the projector, your smartphone or web browser
Read lamp serial numbers and lamp hours on your smartphone with the Christie Connect app
Extend your source options and flexibility with a full range of input connections: 3G-SDI, DisplayPort, HDBaseT™, DVI and HDMI inputs
Christie TruLife™ processing ensures stunning color reproduction
Expert image manipulation with built-in warp and blend functionality
Convenience lighting for easy access and peace of mind in dark environments
360° omnidirectional operation gives you the freedom to position Christie Boxer on any axis
Ready for spectacular visual experiences with 4K
Delivers exceptional HD image quality using Christie's enhanced HD upscaling

Technical Specification

Image Brightness: 30,000 lumens (center), 29,000 ANSI lumens (typical)
Contrast: 2000:1 (Full on:Full off)
Display Type: 3DLP® 1.38"
Native resolution: 4K (4096 x 2160)
Illumination Type: 6X 450W NSH
Estimated Life: 1500hrs to 70% initial brightness
Inputs 2 x Dual 3G HD-SDI input card
2 x Twin DisplayPort input card
HDBaseT
Pixel Clock: 1.2Gpx/s - TruLife electronics
Control and networking Keypad
RS-232
Ethernet (10/100) RJ-45
Christie Control app
Lens mount Tool-free lens insertion system
Boresight adjustable
Motorized horizontal and vertical lens offset
Motorized zoom and focus adjustment
Power requirements operating voltage: 200-240V
operating current: 19A
Dimensions Dimensions: (LxWxH): 37.75 x 23.50 x 12.00" (959 x 597 x 305mm)
Weight: 68kg (150lbs) (without lens)
Operating Environment Temp: 5 – 40°C (40 – 104°F)
Humidity: 10 – 80% noncondensing
